Integrated, segmented fully automatic feed pellet production line, turnkey project, poultry farming

大画像 : Integrated, segmented fully automatic feed pellet production line, turnkey project, poultry farming

商品の詳細:

起源の場所:	中国
ブランド名:	MIKIM
証明:	CE
モデル番号:	フィードペレット生産ライン

お支払配送条件:

最小注文数量:	1
価格:	10000USD
パッケージの詳細:	標準輸出梱包
受渡し時間:	5-8作業日
支払条件:	L/C、D/A、D/P、T/T、Western Union、MoneyGram
供給の能力:	100t/h

連絡先

Integrated, segmented fully automatic feed pellet production line, turnkey project, poultry farming

説明

適用産業:	製造工場、農場、家庭用品	生産:	1〜100トン
関数:	アニアムフィードパフペレットマシン、動物飼料ペレットを生産します	タイプ:	ワンストップソリューション動物飼料ペレットマシン、動物飼料加工機械
特徴:	高効率、低ノイズ、簡単な操作	原材料:	小麦ブラン、トウモロコシ、広く、大豆、わら
ハイライト:	fully automatic feed pellet machine , poultry feed pellet production line , turnkey feed pellet machine project

Integrated, Segmented Fully Automatic Feed Pellet Production Line - Turnkey Project for Poultry Farming

When designing the equipment configuration for a feed production line, a reasonable combination should be made based on production scale, product type, and quality requirements.

Key Design Considerations

Quality & Compatibility: Multifunctional and modular equipment should be selected to facilitate future expansion and upgrades. For example, a pelletizer with adjustable parameters can produce pellets of varying specifications while adjusting production capacity based on market demand.
Automation Level: Automated equipment, such as automatic batching systems and intelligent control systems, can significantly reduce human error and improve production efficiency. Sensors and PLC (programmable logic controller) control systems can be used to monitor and adjust the entire process.
Energy Efficiency: Choosing equipment with low energy consumption and easy maintenance will help reduce operating costs. Equipment should be made of durable materials and designed to facilitate daily maintenance and cleaning.
Production Line Layout: The equipment layout should align with the process flow, minimize material handling distances, and ensure a continuous and efficient production process.

Technical Specifications

Capacity	1-100t/h
Range of Application	Large commercial feed factory, could make chicken, sheep, cow, shrimp feed
Workers Requirements	4-5 people
Shipment Requirements	6×40ft container
Product Advantages	Fully automatic intelligent batching, computer control system with stable output, efficient and continuous operation, labor saving, direct packaging, particle size can be selected from 1-12mm
Size for Whole Line	According to land size and layout

Production Process

Raw Material Pretreatment

Sawdust, as a biomass raw material, requires screening to remove impurities and ensure uniform particle size. Screened sawdust typically requires drying to achieve appropriate moisture content (typically around 10%-20%). Drying can be done naturally in the sun or using specialized drying equipment.

Feeding Process

Pretreated sawdust is conveyed to the feed port of the biomass pellet machine. The feed rate is adjusted based on the pellet machine's production capacity and process requirements to ensure stable and uniform feed.

Pressing Process

Pressure Application: The pressing chamber consists of press rollers and ring die. The press rollers squeeze the sawdust into the ring die's holes, which determine the size and shape of the final pellets.
Frictional Heating: Intense friction raises the temperature (80-100°C), softening lignin which acts as a natural binder to form strong pellets.

Forming and Discharging

Pellets are cut to equal length by the cutting device and discharged through the pellet machine's outlet.

Service and Support

We can build all kinds of fully automatic feed production lines
Customize turnkey production lines according to your needs
Experienced technical experts provide first-class technology and equipment
Complete after-sales service with professional training to maximize project needs
