Automatic feed pellet production line for birds, fish, turtles and pets

大画像 : Automatic feed pellet production line for birds, fish, turtles and pets

商品の詳細:

起源の場所:	中国
ブランド名:	MIKIM
証明:	CE
モデル番号:	鳥、魚、カメ、ペットのための自動飼料ペレット生産ライン

お支払配送条件:

最小注文数量:	1
価格:	11000USD
パッケージの詳細:	標準輸出梱包
受渡し時間:	5-8作業日
支払条件:	L/C、D/A、D/P、T/T、Western Union、MoneyGram
供給の能力:	100t/h

連絡先

Automatic feed pellet production line for birds, fish, turtles and pets

説明

タイプ:

動物のペット飼料生産ライン

原材料:

トウモロコシ/米/穀物

電源:

電気

ハイライト:

automatic feed pellet production line

pet feed pellet machine for birds

fish feed pellet production equipment

Automatic Feed Pellet Production Line for Birds, Fish, Turtles and Pets

Product Specifications

Type	Animal Pet Feed Production Line
Raw Material	Corn/rice/grain
Power Source	Electric

Product Advantages

Quality: Maintains correct raw material ratios for consistent final product quality
Functionality: Produces various pet foods including dry kibble and treats
Productivity: Continuous operation improves speed and efficiency while reducing labor costs

Technical Parameters

Size for whole line	According to land size and layout
Pellet size	1-12mm
Capacity	5-10t/h
Workers requirements	4-5 people
Shipment requirements	5*40ft container
Range of application	Large commercial aquatic/pets feed factory

Process Flow

1. Bucket elevator → 2. Raw materials cleaning system → 3. Silos for crusher → 4. Crusher → 5. Raw material automatic distribution weighing system → 6. Mixing system → 7. Second crushing system → 8. Raw material automatic distribution weighing system → 9. Second mixing system → 10. Extruder → 11. Drying system → 12. Screen system → 13. Seasoning machine → 14. Cooling system → 15. Packing system

Key Features

Nitrided alloy (38CrMoAl) screw for high strength and wear resistance with self-cleaning capabilities
Inverter speed control for feeding, extrusion, and cutting systems with food-grade stainless steel twin-screw feeder
Gearbox with automatic lubrication to extend gear life
Heat sink in transmission system for forced cooling
Water-cooled barrel suitable for various materials including corn, rice, wheat flour and starch
V-belt driven cutter fixed to die head

Detailed System Components

Raw material pretreatment system: Grinder and screener for ultra-fine grinding (80 mesh+) and impurity removal
Mixer: Twin-shaft paddle mixer with ≤5% variation coefficient and temperature control below 40°C
Conditioner: Steam heating at 85-90°C for 20-30 seconds for starch gelatinization
Extruder: Low-shear screw design with density control at 0.3-0.5g/cm³
Drying and Cooling System: Multi-layer belt dryer with staged temperature control (60°C → 50°C → 40°C) to ≤10% moisture content

Additional Specifications

Ingredients: Meat meal, fish meal, corn meal, soybean meal, and other grain meal
Products: Pellet feed including dog food, cat food, fish food, and bird food
Voltage: Three-phase 380V/50Hz or single-phase 220V/50Hz (customizable)
Materials: All machines made of food-grade stainless steel
